PSA Nitrogen Generation System adopts carbon molecular sieve as adsorbent whose capacity of adsorbing the oxygen in air shall be larger more than of adsorbing the nitrogen in air. By means of valve opened and closed with PLC, two columns a&b can be shifted in circulation for pressured adsorption,de-pressured dis-adsorption in turn so as to separate the oxygen and nitrogen in air, thus a nitrogen gas with purity demanded can be made.

PSA Nitrogen Generation System Specifications:

Model	TY3/5 PSA Nitrogen Generation System
Dimensions	570(H)×570(L)×950(W)mm
Application:	Tyre filling
Compressed Air input range	0.4m3/h
N2 Output	3/5m3/h
N2 Output Pressure	0.1-0.65Mpa
N2 Purity	95~99.9%
N2 Storage Tank	0.3m3
Set Pressure Range	0.1-0.65Mpa

Motor Power	0.5KW
Power Supply	110V/220V,50-60Hz
Net/Gross weight	200Kg

PSA Nitrogen Generation System Main parts

Project	Type	Quantity	Remark
PSA adsorption tower	Professional design	2pieces/10kg	Special pressure vessel manufacturer
Carbon Molecular Sieve	MSC-3KT-172	3500kg	Takeda Japan
Vortex airflow distributor	Professional design	2 pieces	Technical Carbotech from Germany
Self complement compact device	Professional design	2sets	Jiangyin Tongyue
single unit processing part	/	1 set	SMC-Japan
Sample pressure reduce valve	/	1 piece	SMC-Japan
Direct current 24V power	/	1 set	Taiwan-Mingwei
Pneumatic valves Pneumatic valves	DN100	5 pieces	Burkert Germany Burkert Germany
	DN50	4 pieces
	DN20	1 pieces
Magnetic valve	4V210-24V	10 pieces	Taiwan Airtac
Metal flow meter	LZZ-50	1 piece	Changzhou Shuanghuan
Control system	TPC7062K	1set	(color touch screen )Kunlun Tongtai
Muffler	TY-500X	1 set	Jiangyin Tongyue
Pipe valve system	bprofessional produce	1 set	Jiangyin Tongyue
