When the process adopts lifting air, oxygen and nitrogen have different diffusion rate and adsorptive capacity to separate oxygen from nitrogen on carbon molecular sieve. When air is compressed to 0.8MPa, air source enters in pressure-swing adsorption tower for separation after being purified through dry and oil-water separation process (filter). Oxygen molecules are diffused and adsorbedin carbon molecular sieve under pressure. Non-adsorbed nitrogen is discharged from outlet of adsorption tower. Oxygen is desorbed, discharged and purged in adsorption tower under depressurization. Moreover, adsorbent can be recycled.

Application:

Food packing, Food storing, Electric & Electronic industry, Petro-gas & Oil field, Chemicals & Petro-chemicals, Coal-mine, Metallurgy, Pharmacy, SMT, Fire-resistance, lab, Air driving, and so on...
1. Metallurgy: For anneal protection, agglomeration protection, nitrogenizing, furnace washing and blowing ,etc. Used in fields such as metal heating treatment, powder metallurgy, magnetic material,copper process, metallic mesh, galvanized wire, semiconductor, etc.

2. Chemical and new material industries: For chemical material gas, pipeline blowing, gas replacement, gas protection, product transport, etc. Used in fields such as chemical ,urethane elastic fiber, rubber, plastic, tyre, polyurethane, biological technology, intermediate, etc.

3. Electronic industry: For encapsulation, agglomeration, anneal, deoxidization, storage of electronic products. Used in fields such as peak welding, circumfluence welding, crystal, piezoelectricity, electronic porcelain, electronic copper tape, battery, electronic alloy material, etc.

Our Service

Pre-sale services

Advisory Services: Solve your problems one to one, and provide the most suitable and energy saving plan.

Technical Support: Provide you the security drawings of the whole machine and technological equipment flow chart; send our technician on mission to help you if needed.

After-sale Service

Technical Support: Provide free installation guide and operation training, and the after-sale technical documents to the customers.

Quality Assurance: Three guarantees are valid in one year since the machine leave the factory. We provide maintenance service during all the machine’s life.

Customer Service: We will make periodical return visit in order to know the service condition of the machine.

Specifications:

Model

Capacity(Nm3/h)

Purity

Power(KW)

Overall size(mm)

TY-3-39

TY-5-29

TY-5-295

TY-8-295

99.9%

99.5%

99%

95%

0.5

1800*1400*1500

TY-5-49

TY-8-39

TY-12-295

TY-15-29

99.99%

99.9%

99.5%

99%

0.5

1800*1400*1800

TY-10-49

TY-15-39

TY-25-295

TY-30-39

99.99%

99.9%

99.5%

99%

0.5

2000*1700*2250

TY-15-49

TY-22-39

TY-35-295

TY-45-29

99.99%

99.9%

99.5%

99%

0.5

2100*1800*2200

TY-20-49

TY-30-39

TY-50-295

TY-60-29

99.99%

99.9%

99.5%

99%

0.5

2200*1800*2200

TY-30-49

TY-45-39

TY-75-295

TY-88-29

99.99%

99.9%

99.5%

99%

0.5

2400*1900*2200

TY-40-49

TY-60-39

TY-100-295

TY-120-29

100

120

99.99%

99.9%

99.5%

99%

0.5

2500*2100*2500

TY-50-49

TY-70-39

TY-120-295

TY-140-29

120

140

99.99%

99.9%

99.5%

99%

0.5

2600*2200*2850

TY-60-49

TY-90-39

TY-160-295

TY-190-29

160

190

99.99%

99.9%

99.5%

99%

0.5

2800*2200*2500

TY-80-49

99.99%

0.5

TY-120-39

TY-200-295

TY-250-29

120

200

250

99.9%

99.5%

99%

0.5

3200*1400*2800

TY-100-49

TY-140-39

TY250-295

TY-290-29

100

140

250

290

99.99%

99.9%

99.5%

99%

0.5

3500*1500*2800

...
