High Purity 99.99% PSA Nitrogen Generator Complete System Box Style

Edible oil filler high purity 99.99% PSA nitrogen generator complete system box style

Product Description

When the pressure rises, the carbon molecular sieve adsorbs the oxygen and produces the nitrogen gas. When the pressure decreases, the carbon molecular sieve starts to desorb the oxygen until the pressure equals to the ordinary pressure. At that time, the carbon molecular sieve desorbs the oxygen completely. The PSA nitrogen generator is usually equipped with adsorption towers. It controls the pneumatic valve by PLC, thus the two adsorption towers can produce the nitrogen gas alternatively. One tower adsorbs the oxygen and produces nitrogen gas, the other desorbs to regeneration to produces the required nitrogen.

SMT nitrogen generator combines the features of lead-free soldering in SMT industry, nitrogen purity is generally between 99.9%～99.999%, the flow of nitrogen generator of each soldering furnace is generally between 10～30Nm3/hr (special specifications are calculated according to actual flow), the dew point is between -40℃～-60℃, and nitrogen pressure is between 0.5-0.6MPa. SMT dedicated nitrogen making solution can make the flux correct and active, reduce the residual amount of flux, enhance soldering quality and make the soldered surface more attractive.

Nitrogen flow: 0-2,000Nm3/h O2: ≤1ppm Dew point: ≤-70℃  Nitrogen purity: 99.99%-99.999%

molecular sieve cave. That’s all for the PSA nitrogen generation process.

Nitrogen flow: 0-2,000Nm3/h O2: ≤1ppm Dew point: ≤-70℃  Nitrogen purity: 99.99%-99.999%

Equipment Features

Main Features:

1. Good stability, oxygen content can be controlled to be less than 5ppm at any time.

2. High purity, capability of keeping long-term stability when nitrogen purity is 99.9995%.

3. High reliability, manufactured according to the international standard.
