Small Volume Modular 20nm3/H Pressure Swing Adsorption Nitrogen Generation 99.99%
关键词:
制氮机、空压机、制氧等气体处理设备
产品描述
Small volume Modular nitrogen generator 20Nm3/h with high purity 99.99%
| Model | Specification | |
| G-5MZ | ||
| N2 capacity | Nm3/Hr | 20 |
| N2 purity | % | 99.99% |
| N2 outlet pressure | Mpa | 0.1~0.6 |
| Air inlet pressure | MPa | 0.7~0.8 |
| Air inlet temperature | ℃ | ≤38 |
| Dew point | ℃ | ≤-40 |
| Working condition | ||
| Air compressor flow | m³/Min | 0.5 |
| Max working pressure | MPa | 0.8 |
| Ambient temperature | ℃ | 40 |
| N2 outlet dia | DN | 15 |
| Air inlet dia | DN | 15 |
| Working cycle | S | 40-55 |
| Regeneration mode | Pressure swing analysis and alternate purging | |
| Voltage: | 220V/50Hz | |
| Pneumatic valve | mm | DN15*5 |
| Muffler | mm | customizing |
| Adsorbent | CMS260 | 1 batch |
| Controller | PLC | Siemens |
